Tenda W330R User Manual

Wireless-N Broadband Router
Appendix A: Product Features
◆ Integrates router, wireless access point, four-port Gigabit
switch and firewall in one
◆ Complies with IEEE802.11n (Draft 2.0), IEEE802.11b
and IEEE802.11g standards
◆ MIMO technology utilizes reflection signal to increase 8
times transmission distance of original 802.11g standard
and reduces the "dead spots" in the wireless coverage
area
◆ Provides 300Mbps receiving rate and 300Mbps sending
rate
◆ Supports WMM to make your voice and video more
smooth
◆ Supports 64/128-bit WEP, WPA, WPA2 encryption
methods and 802.1x security authentication standard
◆ Setup Wizard support for fast and easy configurations
◆ WPS (PBC and PIN) encryption method to free you from
remembering long passwords
◆ Supports remote/local Web management
◆ Supports wireless Roaming technology to ensure high-
efficient wireless connections
◆ Supports wireless SSID stealth mode and MAC address
access control
◆ Supports Auto MDI/MDIX
◆ Provides system log to record the status of the router
85

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
