Tenda W330R User Manual

Wireless-N Broadband Router
a wireless client’s PIN
code in the field and keep
the same code in the
client.
WDS Settings
In this mode, you can
expand the scope of
network by combining up
to four other access points
together, and every
access point can still
accept wireless clients.
Lazy Mode: You need
configure the router’s
BSSID into another
device, not need input
another router’s BSSID in
it, and then connect
together automatically.
Bridge Mode: You can
wirelessly connect two or
more wired networks via
this mode. In this mode,
42

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
