Chapter 7: DHCP Server
DHCP (Dynamic Host
Control Protocol) is to
assign an IP address to the
computers on the LAN/
private network. When you
enable the DHCP Server,
the DHCP Server will
allocate automatically an
unused IP address from the
IP address pool to the
requesting computer in
premise of activating
“Obtain an IP Address
Automatically”. So
specifying the starting and
ending address of the IP
Address pool is needed.
DHCP Server: Activate the
checkbox to enable
DHCP server.
IP Address Start/End:
Enter the range of IP
address for DHCP server
distribution.
Lease Time: The length of
the IP address lease.
49

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
