Tenda W330R User Manual

Wireless-N Broadband Router
firewall settings of
the DMZ host will
not function.
UPnP Settings
It supports latest Universal
Plug and Play. This
function goes into effect
on Windows XP or
Windows ME or this
function would go into
effect if you have installed
software that supports
UPnP. With the UPnP
function, host in LAN can
request the router to
process some special port
switching so as to enable
host outside to visit the
resources in the internal
host.
Enable UPnP: Click the
checkbox to enable the
UPnP.
62

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
