Tenda W330R User Manual

Wireless-N Broadband Router
Chapter 9: Traffic Control
Traffic Control
Traffic control is used to
limit communication speed
in the LAN and WAN. Up
to 20 entries can be
supported with the
capability for at most 254
PCs' speed control,
including for IP address
range configuration.
Enable Traffic Control:
To enable or disable the
internal IP bandwidth
control.
Interface: To limit the
uploading and
downloading bandwidth in
WAN port.
Service: To select the
controlled service type,
such as HTTP service.
IP Starting Address: The
63

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
