Tenda W330R User Manual

Wireless-N Broadband Router
external server send
request traffics to internal
clients with the range of
1～65535. Note that the
low number first and two
blanks can keep the same
number if needed.
Apply: To enable or
disable the rule.
Add: After edit the rule,
click the “add” button to
add the current entry to
port triggering list.
Apply: Click “Apply” to
activate the current rule.
Cancel: Click “Cancel” to
drop all setting saved last
time.
It is allowed to delete or
modify the previous rules
in the list table.
Note:
The special
application can be
57

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
