Internet.
Policy Name:Enter a
name for the access policy
selected.
IP Start/End:Enter the
starting/ending IP address
Port No.: Enter the port
range based over the
protocol for access policy.
Protocol:Select one
protocol (TCP/UDP/Both)
from the drop-down menu.
Times:Select the time
range of client filter.
Days: Select the day(s)
to run the access policy.
67

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
