Terex DTM 00101 (standard) - Safety Signs (ANSI)

2.4 (ANSI) Safety Signs
The safety signs are located in/on the machine as indicated. (Descriptions of the
symbols are provided in section 2.3)
Key
1. Fall hazard
2. Pre-Cleaner Notice
3. Read operator’s manual / fall hazard (inside cab enclosure / fire notice)
4. Skin (oil) injection hazard
5. Entanglement hazard (engine compartment)
6. Clean undercarriages notice
7. Tie down location (found beneath loader in front locations)
8. Crush hazard (run over)
9. Crush hazard (lift arm brace)
10. Crush hazard (lift arms)
CRUSH HAZARD
Contact with moving machine can
result in death or serious injury.
Keep clear of moving machine.
2030-593
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Keep clear of lift arms and
attachments.
2030-592
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Install lift arm brace prior to servicing.
2030-594
Fall Hazard
Serious injury or death can result
from falling.
Use the provided access system when
entering or exiting the machine.
2030-597
Injection Hazard
Escaping fluid under pressure can
penetrate skin, causing serious injury.
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pinholes.
• Use cardboard to check for leaks.
Fluid injected into skin must be surgi-
cally removed within a few hours by a
doctor familiar with this type of injury
or gangrene will result.
2030-602
Improper operation or maintenance
can result in serious injury or death.
Read and understand the opera-
tor’s manual and all safety signs
prior to operating or maintaining
the machine.
Fire Hazard
Flammable debris can collect near
hot components and lead to a fire.
Read Operator’s Manual
Keep the engine, exhaust and
chassis areas free of debris.
Do not use the bucket/attachment
as a work platform.
Fall Hazard
Falling can result in serious injury
or death.
1
4
10
3
7
9
8
Entanglement Hazard
Rotating parts can cause personal injury.
Keep away from fan and belt while the
engine is running. Stop engine before
servicing.
2030-600
5
14
2 SAFETY
Inspect undercarriages daily for
accumulation of debris. If debris
is present, clean thoroughly with
a pressure washer. If debris is
allowed to build up, it can cause
premature component wear and
decrease machine performance.
2085-253
NOTICE
6
This machine is equipped with an extended intake air pre-
cleaner assembly. The pre-cleaner assembly must be
removed prior to raising the cab to avoid damage.
2085-251
NOTICE
2
WARNING
WARNING
A
R
WARNING
WARNING
WARNING
WARNING
WARNING
7
