7.22 Electrical System
The electrical systems in PT machines are equipped with fuses that help to pro-
tect the electrical components from damage. They are found in the fuse panel
enclosure which is located behind the panel cover in the right rear corner of the
interior of the cab behind the operator seat.
In the event of an electrical malfunction, check the fuse panel. Remove the fuse
related to the component that is not working properly and inspect it. If it appears
damaged in any way, replace it.
40
50
50
40
50
20
30
20
60
80
10
10
5
20
30
5
30
20
30
5
MACHINE CONT
MAIN A
MAIN B
MAIN C
ENGINE ECU
LIGHTS
AUX LOADER
MAIN
PWR A
MAIN
PWR B
MAIN C
STARTER
LIGHTS MACHINE ECU
CONDENSOR
WIPER
HEATER VALVE
STARTER
HEATER
FUEL
SEND
POWER
OUTLET
DISPLAY
OUTPUT
MODULE
ELECTRICAL PANEL
INCLINOMETER
40 A. RELAY
# 87417B
GLOW PLUG A
40 A. RELAY
#87417B
AUX LDR G
40 A. RELAY
#87417B
AUX LDR D
40 A. RELAY
#87417B
40 A. RELAY
#87417B
GLOW
PLUG B
GLOW PLUG
RADIO
2075-840
5
15
IGNITION
5
BEACON
5
ALTERNATOR
40 A. RELAY
#87417B
ECU START
OVERRIDE
AUX LDR C
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
35 A. RELAY
#G8V-RH-
1C7T-R-DC12
40 A. RELAY
#87417B
AUX
LOADER B
HORN
10
