4.3 Throttle
The throttle (foot pedal) is located beneath the operator’s right foot when seated
in the machine. The throttle controls engine rpm.
• Press the front of the pedal down to increase engine RPM.
• Press the rear of the pedal down to decrease engine RPM.
• Select a lower rpm for work that requires delicate operation of
the machine.
• Select a higher rpm for faster travel speed or when more
power or flow is required for a task.
4.4 Operator Seat
Seat Adjustment
the PT-100G is available with a
suspension style seat adjustable
for both operator weight (spring
pre-load) and operator height
variation in fore and aft direc-
tions.
To adjust for weight:
Twist the knob clockwise for
heavier operator or counter-
clockwise for lighter operator.
To adjust for height:
Pull outward on the height
adjustment lever, slide the seat forward or rearward as needed, then release the
lever to set
.
4.5 Two Speed
The PT-100G is equipped with a two-speed drive system. Low range is best suit-
ed to performing strenuous work or operating attachments. High range is intend-
ed mainly for transporting.
To shift between high and low ranges, push the button on the front of the left
joystick. When shifting between ranges, slow the machine to ensure a smooth
transition. The high range indicator (item 9, section 4.1) illuminates to confirm
high range operation.
Note: If the machine is turned off, the lap bar is raised, or the operator exits the
seat, the machine automatically returns to low range.
4 MACHINE DESCRIPTION / CONTROLS
weight
height
43
