Terex DTM 00101 (standard) User Manual

3.6 Transmission PT-100G PT-100G F
3.7 Auxiliary Hydraulics PT-100G PT-100G F
3.8 Ground pressure PT-100G PT-100G F
3.9 Operating Specs. PT-100G PT-100G F
Note: The Maximum Gross Vehicle Weight of the PT-100G is not to exceed 13500
lb (6123 kg.). This excludes an operator, but does include accessories, attach-
ments and material being carried.
3.10 Refill Capacities (approx.) PT-100G PT-100G F
Make
Rexroth Rexroth
Type
A10VG63 A10VG63
Design
Axial piston Axial piston
Displacement
3.84 in.³ (63 cc) / rev. 3.84 in.³ (63 cc) / rev.
Relief Pressure
5500 psi (37,920 kPa) 5500 psi (37,920 kPa)
Make
Rexroth Rexroth
Type
A10VO85 A10VO85
Design
Axial Piston Axial Piston
Displacement
5.19 in. ³ (85 cc) /rev. 5.19 in. ³ (85 cc) /rev.
Relief press. Low Flow
3300 psi (22,750 kPa) 3300 psi (22,750 kPa)
Relief press. High Flow
3800 psi (26,200 kPa) 3800 psi (26,200 kPa)
Low Flow @2200 RPM
0-20 gpm (0-75.7 lpm) 0-20 gpm (0-75.7 lpm)
High Flow @2200 RPM
30-43 gpm (114-163 lpm) 30-43 gpm (114-163 lpm)
At operating weight (18")
4.5 psi (31 kPa) (18" trk)
At shipping weight (18")
4.1 psi (28.3kPa) (18" trk)
At operating weight (20")
4 psi (27.6kPa) (20" trk) 4 psi (27.6kPa) (20" trk)
At shipping weight (20")
3.7 psi (25.5kPa) (20" trk) 3.7 psi (25.5kPa) (20" trk
)
Tipping load
8000 lb (3629 kg) 8000 lb (3629 kg)
Operating capacity 50%
4000 lb (1814 kg) 4000 lb (1814 kg)
Operating capacity 35%
2800 lb (1270 kg) 2800 lb (1270 kg)
Fuel tank
30gal(113.6l) 30gal(113.6l)
Hydraulic tank
22gal(83.3l) 22gal(83.3l)
Engine coolant
4.3gal(16.3l) 4.3gal(16.3l)
Engine oil including filter
9qt.(8.52l) 9qt.(8.52l)
Planetary Drive
.95qt.(.9l) .95qt.(.9l)
37
3 TECHNICAL DATA
