7. Radiator/Oil Cooler
Disassembly and Assembly
Chapter Overview
This chapter provides disassembly and assembly
procedures for the radiator/oil cooler assembly.
Personal Safety
Improper or incomplete maintenance/repair of a Compact
Track Loader can be dangerous and may result in ma-
chine damage, injury or death.
Do not attempt to perform any type of repair or mainten-
ance on a Compact Track Loader until you have read and
fully understood the information in this manual.
Refer to the Operation and Maintenance manual for in-
structions regarding proper machine operation techniques
before operating any Compact Track Loader.
Prior to performing any type of service work on a
Compact Track Loader, read and understand Chap-
ter 1 (Product Safety) for personal safety informa-
tion.
Machine Preparation
Accidental machine starting can cause injury or
death to personnel working on a Compact Track
Loader.
As a precaution, disconnect the battery cables from
the battery terminals, tape the battery clamps and
remove the key from the ignition switch prior to per-
forming any service work on a Compact Track Load-
er.
Place a “Do Not Operate” tag prominently on the
machine to inform personnel that the machine is be-
ing worked on.
Radiator/Oil Cooler
Disassembly and Assembly
Procedures
Disassembly and assembly procedures are provided
for the following radiator/oil cooler components.
• Fan Guard
• Fan
• Radiator/Oil Cooler
• Reversible Fan Compressor and Control Box
Note: Procedures are provided for only those radiator/oil
cooler components listed above. However, information for
removal and installation of other radiator/oil cooler compo-
nents can be obtained from the machine specific parts
manual.
Note: Refer to Figure 3-1 for an overview of the filtering
and cooling system.
Fan Guard Removal and In-
stallation
The tools required for fan guard removal and instal-
lations are listed below. Use manufacturer-
recommended tools whenever possible.
Required Tools
Combination Wrench
To Next Page
