Terex RL4000 Operator's Manual

Operator's Manual
First Edition • Second Printing
Part No. 116692 RL4000 • TML-4000 31
Operating Instructions
Operation of Lights
Note: The engine must be running before the lights
are turned on.
1 Turn on the main circuit breaker switches on the
control panel.
2 Turn on the lights using the individual light
switches.
3 Turn the lights off using the individual light
switches.
Note: Make sure the lights are turned off before
shutting down the engine.
Grounding
If your light tower has the optional
grounding rod, drive the grounding
rod into the ground and connect to
the grounding lug located on the
chassis at the rear of the light
tower.
Note: This machine should be
grounded in accordance with all local electrical
codes. Consult the local electrical codes or
authority having jurisdiction in the area where the
machine will be used for specific requirements.
Electrical Outlets
A 120V/20 amp GFI duplex receptacle and a 240V/
30 amp T-lock receptacle are located on the control
panel inside the light tower cabinet.
Note: Before plugging in auxiliary power cords, feed
them up through the trailer frame and attach to the
receptacles. Close the cabinet doors to protect the
control panel and other components from weather.
Towing
1 Make sure the mast is rotated to its original
position and secured. Line up the arrows on the
front of the mast.
2 Turn the extend/retract winch handle
counterclockwise until the mast sections fully
retract.
3 When the mast sections are fully retracted,
remove the cotter pin and the lower retaining pin
from the lower mast support.
4 Lower the mast by turning the raise/lower winch
counterclockwise.
5 When the mast is fully lowered, insert the upper
retaining pin and the cotter pin.
6 Insert the lower retaining pin into the storage
hole provided in the mast support and insert the
cotter pin.
7 Make sure the covers are closed and secured.
8 Raise the side outrigger jacks and the rear
leveling jack. Rotate them into the stowed and
secured position.
9 RL4000: Release the spring pin on the side
outriggers and slide the outriggers into the
stowed and secured position. Make sure the
outriggers are locked in place.
9 TML-4000: Pull the release pin on the side
outriggers and raise the outriggers into the
stowed and secured position. Rotate the
leveling jack into the stowed and secured
position.

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
