Terex TR100 User Manual

8-6
Lubrication and Servicing
LUBRICATION AND SERVICE CHART (Continued)
Interval Ref. No. of
Hours Points Identification Service Instructions Points Lubricant Service/Quantities
- Engine Fuel Filters Replace filters. 2 - Maintenance
Manual 110-0030
- Engine Coolant Additive Check DCA concentration and replenish. - DCA4 See Page 8-7
- Engine Coolant Filter(s) Replace filter(s) if required. - - See Page 8-7
- Engine Crankcase Breather Clean. 1 - Maintenance
Manual
7 Engine Cooling Fan Check condition. 1 - See Page 8-7
250 16 Engine Power Takeoff Drain and refill. 1 EPL See Page 8-8 / 9
17 Differential Check oil level. Add if low. 1 EPL -
18 Wheel Planetaries Check oil level. Add if low. 2 EPL -
- Differential Breather Clean. 1 - -
- Transmission Breather Clean. 1 - -
- Alternator Drive Belt Check belt tension. Adjust if required. 1 - See Page 8-7 / 8
- Accessory Drive Belts (if fitted) Check belt tension. Adjust if required. - - See Page 8-7 / 8
- Front Brake Pads Check wear. Replace as required. 2 - See Page 8-8
1 Engine Drain and refill 1 EO See Page 8-8 / 9
- Engine Oil Filters Replace Filters - - Maintenance
Manual 110-0030
19 Fuel Tank Clean filler neck screen and cap. - - -
500 20 Accumulators Check nitrogen pressures. 3 - -
21 Driveline Universal Joints Lube (if grease nipple fitted). - *EP, NLGI See Note A
22 Driveline Slip Joints Lube (if grease nipple fitted). - *EP, NLGI See Note A
23 Steering Column Universal Joints Lube. 3 *EP, NLGI See Note A
- Hydraulic & Steering Tank Breather Clean. 1 - -
- Hydraulic System Pressure Checks Check pressures at check points. - - See Page 8-8
- Main Hydraulic Filter Replace elements. 2 - See Page 8-8
1 000 6 Rear Disc Brake Filter(s) Replace element(s). 2 - See Page 8-8
2 Transmission Drain and refill. 1 EO See Page 8-8 / 9
- Transmission Oil Filter Replace element. 1 - -
24 Steering In-line Filter Replace element 1 - -
- Engine Crankcase Breather Clean/Replace 1 - -
17 Differential Drain and refill 1 EPL See Page 8-8 / 9
1 500 18 Wheel Planetaries Drain and refill 2 EPL See Page 8-8 / 9
- Fan Idler Pivot Arm Lube 1 EP, NLGI See Note A
3 Main Hydraulic Tank Drain and refill 1 HO See Page 8-8 / 9
- Main Hydraulic Tank Suction Screens Remove and clean 3 - -
4 Steering / Braking Tank Drain and refill 1 HO See Page 8-8 / 9
2 000 - Steering / Braking Hydraulic Tank Filter Replace element 1 - See Page 8-8
- Steering / Braking Tank Suction Screen Remove and clean 1 - -
19 Fuel Tank Drain and refill 1 Diesel See Page 8-8 / 9
25 Rear Brake Packs Drain and refill 2 HO -
4 000 27 Cooling System Drain, flush and refill 1 Antifreeze See Page 8-8 / 9
- Air Conditiong Compressor Drain, flush and refill 1 PAG Oil See Page 8-8 / 10
5 000 26 Front Wheel Bearings Repack 2 *EP, NLGI *
* - Fill compartment one half full.
Note A -Lubricate slowly until excess lube is seen.
EO - Engine Oil. Refer to chart under 'Recommended
Lubricants'.
EPL - Extreme Pressure Gear Lubricant meeting
specification MIL-L-2105C.
HO - Hydraulic Transmission Oil meeting
Specification EMS19058 Refer to chart under
'Recommended Lubricants'.
EP, NLGI - Extreme Pressure Lithium No. 2 Grease.
Refer to chart under 'Recommended
Lubricants'.
*EP, NLGI - Extreme Pressure Lithium No. 2 Grease
(without 'Molybdenum'). Refer to chart Under
'Recommended Lubricants'.
PAG Oil - Polyalklene Glycol (PAG) Compressor
Lubricating Oil - Low Viscosity (ISO46).
