Controls and Operating
CONTROLS AND INSTRUMENTS
1622
1. Face Vent/Side Window Demister
2. Warning Lights
3. Tachometer/Hourmeter
4. Engine Water Temperature Gauge
5. Engine Oil Pressure Gauge
6. Fuel Gauge
7. Warning Lights
8. Transmission Oil Pressure Gauge
9. Transmission Oil Temperature Gauge
10. Speedometer/Odometer
11. Warning Lights
12. Face Vent
13. Parking/Emergency Brake Control
14. Cup Location
15. Windscreen Demister
16. Side Window Demister
17. Document Holder
18. Fuse Box Cover
19. Transmission Gear Shift Selector
20. Retarder Control
21. Spotting Brake Control
22. Ignition and Starter Key Switch
23. Switches
24. Air Conditioner Control
25. Blower Control
26. Heater Control
27. Accessory Lamp Socket
28. Accelerator Control
29. Service Brake Control
30. Steering Wheel
31. Steering Wheel Adjustment Lock
32. Headlight Dipper,
Direction Indicator,
Windscreen Wiper/Washer and
Horn Control
33. Radio/Cassette Player
34. Cold Start Pilot
35. Foot Rest
36. Body Control Lever
37. Electric Window Switch
38. Interior Light (Not Shown).
Located above dash.
39. Cup Holder (Not Shown). Located on
back wall.
1 2 3 4 56 78 9 10 11 12 13 14 15 16
17
18
19
20
22
23
242526
27
28
29
30
31
3233
34
35
36
37
21
