Terex TR100 User Manual

2-20
Safety
DECALS AND INSTRUCTION
PLATES
Decals and instruction plates fitted to
vehicles may vary from country to
country to suit local needs. These pages
contain a brief description and the
location of the decals and instruction
plates that may appear on your vehicle.
1. Tyre Warning
2. Accumulator Precautions
3. Accumulator Charging Instructions
4. Operating On A Grade Instructions
5. Vehicle Parking Instructions
6. Acoustic Foam Precautions
7. Symbol Identification Chart
8. Radiator Cap Warning
9. Radiator Fill Instructions
10. Air Cleaner Information
11. Vehicle Overall Height
12. Steering Wheel Lock
13. Negative Earth
14. Battery Cable Warning
15. Ride Strut Pressure Warning
1. Alternator Precautions
2. CEC (ATEC) Welding Warning
3. Engine Instructions
4. Body Control Lever Positions
5. Retarder Positions
6. CEC (ATEC) Switches
7. Pre-operating Instructions
8. Acoustic Foam Precautions
9. Pre-operating Instructions
10. Hydraulic Oil Decal
11. Sight Gauge Plate
12. Hydraulic Oil Pressure Plate
13. Anti-Syphon Instructions
14. Instruction Plate
15. Hydraulic Oil Level
16. Instruction Decal
17. Hydraulic Oil Level
18. Lubrication Chart
19. Pressure Test Points
20. Accumulator Charging Instructions
21. Accumulator Precautions
22. Pressure Test Points
23. Pressure Test Points
24. Ride Strut Pressure Warning
25. Machine Serial Plate
659
1
15 113, 14
2, 3
6
4, 5
7
11, 12
8, 9
10
2075
2, 3, 4, 5, 6, 7
1
8
9
10
13
11
12
14
16
15 17 14
13
18
25
24
22, 23
20, 21
19
