Page 21
4.1.2.5 SETTING THE NUMBER OF ENCODER PULSES
♦ Select: ENCODER PULSES: 100 (or another pre-set value) represents the
number of pulses per revolution transmitted by the encoder
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 1000
& Press: to confirm the selection and return to the machine parameter edit
menu
or
& Press: to return to the menu without saving any changes made
4.1.3 SETTING THE ANALOGUE PARAMETERS
& Press: or to navigate the menu and select the ANALOGUE
PARAMETERS function
♦ Select: ANALOGUE PARAMETERS
& Press: to access the settings page of the analogue parameters
The following appears: SENSOR:
FULL SCALE (daN):
LIMIT CHANGE (daN):
MAX DELTA BIT ADC:
SAMP. FREQUENCY (Hz):
SAMPLES BY AVERAGE:
4.1.3.1 SETTING THE TYPE OF SENSOR
♦ Select: SENSOR: Cell (or Trans.4-20)
& Press: to select Cell if a load cell is used
or
& Press: to select Trans.4-20 if a pressure transducer is used
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
4.1.3.2 SETTING THE PULL FULL SCALE
♦ Select: FULL SCALE (daN): 4500 (or another pre-set value) corresponds with
the intended pull in correspondence with the full scale value of the
sensor used
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 25000 daN
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
4.1.3.3 SETTING THE LIMIT CHANGE
♦ Select: LIMIT CHANGE (daN): 0 (or another pre-set value) corresponds with
the variation step of the pull limit, which can be implemented
while the applied pull is being monitored (refer to paragraph 3.7
BEGINNING AND END OF THE MONITORING PROCESS)
