Page 20
The following appears: CAPSTAN DIAM (mm):
MAX. ROPE DIAM (mm):
CAPSTAN TEETH:
ENCODER TEETH:
ENCODER PULSES:
4.1.2.1 SETTING THE CAPSTAN DIAMETER
♦ Select: CAPSTAN DIAM (mm): 1200 (or another pre-set value)
represents the bottom groove of the capstan expressed in mm.
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 2500 mm.
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
4.1.2.2 SETTING THE MAXIMUM ROPE DIAMETER
♦ Select: MAX. ROPE DIAM (mm): 100 (or another pre-set value)
represents the max. diameter intended for the rope or conductor
on the machine expressed in mm.
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 100 mm.
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
4.1.2.3 SETTING THE NUMBER OF CROWN GEAR TEETH
♦ Select: CAPSTAN TEETH: 200 (or another pre-set value) represents the
number of crown gear teeth of the capstan
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 1000.
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
4.1.2.4 SETTING THE NUMBER OF ENCODER TEETH
♦ Select: ENCODER TEETH: 25 (or another pre-set value) represents the
number of teeth of the metre counter wheel connected to the
encoder
& Press: or until the desired value is selected
ATTENTION: the values range from 1 to 100
& Press: to confirm the selection and move on to the next parameter
or
& Press: to return to the menu without saving any changes made
