TESTO 454 Getting Started

6. Measurement example
52
6.3 Long-term measurement of HVAC with the
Control Unit and logger
6.3.1 Initial operation
Recording of temperature, humidity and CO2 over a longer period.
Readings can only be stored where the associated probe is connected.
·
Control Unit and logger are connected to each other.
·
Probes are connected.
·
Analyser is switched on.
6.3.2 Entering a measuring program
1
Select –> –> -> .
Three starting criteria:
·
Manual:
The measuring program can be started at any time using the function key “Start”.
·
Date/Time:
The measuring program is started at a pre-programmed time.
·
Overshoot/Shortfall:
The measuring program is started depending on specified events.
2
Select manual and confirm with .
-
Automatically activates the “Measuring rate” menu:
3
Enter measuring rate in seconds (in this case 5 min = 300 sec).
4
Confirm with .
-
The End menu is activated automatically:
End criteria:
· Memory full:
Reading recording stops when the reading memory is full.
· Number of values:
A desired number of values is recorded.
· Date/Time:
Reading recording stops at a specified time.
5
Select stop condition .
6
Start via “Start” function key.
A running measuring program can be stopped at any time with .
6.3.3 Reading out and printing data
1
–> –> .
-
Displays the stored reading files.
2
Select individual data records with .
3
generates a printout of the data record on the integrated printer, specify-
ing the starting time, the stopped time and the time of printing.
Print
Read-ooutMemory
Stop
Memory ffull
Stop
StartProgramMemory
Logger program menu
Overview of input measuring
program
Display of reading files
