6 Performing the measurement
19
6.2 Setting measuring functions
1 - Open the Measurement submenu.
The submenu with measurement functions opens:
∑ Pixel mark:
o Single point measurement: the temperature measuring
point in the centre of the image is marked with white
crosshairs and the value is displayed.
o Coldspot, Hotspot: the lowest or highest temperature
measuring point is marked with blue or red crosshairs and
the value is displayed.
∑ Measurement range: choose between two temperature
ranges.
∑ Differential temperature: identifies the difference between two
temperatures.
∑ IFOV: the IFOV warner shows what can be measured
accurately from a specific distance.
2 - Move the joystick up/down to select the required function and
then press OK.
