7 Maintenance
38
7.4.2 Update with IRSoft
7.4.2.1 Prepare the Camera

Battery is fully charged or charger is connected to the camera.
1 - Connect computer to camera with USB cable.
2 - Switch on camera.

Firmware is downloaded completely.
7.4.2.2 Execute Update

- IRSoft is activated.
1 - Select Camera -> Configuration.
2 - Click Configure camera.

Window Camera Settings is opened.
3 - Camera Settings -> select Firmware Update -> OK.

FW_T87x_Vx.xx.bin is displayed.
4 - Select Open.

Firmware Update is executed.

Automatic restart of the thermal imager. Update executed
successfully.
Camera coul possible display: Firmware Update finished. Please
restart the device. Restart will not be done.
Action:
- Switch off the camera after 10 s and switch on after 3 s.
 The current Firmeware version is displayed.
