6 Performing the measurement
30
Temperature unit
The temperature unit can be set.
1 - Open the Temperature unit submenu. For how to proceed: see
Getting to know the menu.
2 - Move the joystick up/down to select the required unit and then
press OK.
Set time/date
Time and date can be set. The time and date format are set automatically
based on the selected user interface language.
1 - Select the Set time/date function.
2 - Move the joystick to the right/left to select the required setting
option.
3 - Move the joystick up/down to set the value.
4 - After setting all values, press OK.
Power-save options
The illumination intensity of the display can be set. A lower intensity increases
the battery life.
The time until automatic switch-off can be set.
1 - Select the Power-save options function.
2 - Move the joystick up/down to select the required intensity level
and then press OK.
6.9.2 SuperResolution
SuperResolution is a technology to improve image quality. Each time an image
is recorded, a sequence of images is saved on the thermal imager and used to
calculate an image with four times more readings, with the aid of the camera ,
the App or PC software (no interpolation). The geometric resolution (IFOV) is
improved by a factor of 1.6.
To use the function, the following conditions must be fulfilled:
∑ The camera is hand-held.
∑ The objects to be imaged do not move.
