CBLé System Guidebook 57
Error
Code Error Description
E.30
Invalid filter selected. (Must be an integer from 0–6.)
E.32
Sample time out-of-range (see pages 39, 70).
E.33
Invalid number of samples selected. (Must be L1, an integer from
1–256 if Statistics is on in
CMD1
, or an integer from 1–512 if Statistics
is off.)
E.34
Invalid trigger type option. (Must be an integer from 0–6, or an integer
from 10000–19999.)
E.35
Invalid trigger channel. (Must be 0, 1, 2, 3, or 21.)
E.36
Invalid or out of range trigger threshold (see page 42).
E.37
Invalid prestore value. (Must be an integer from 0–100.)
E.38
Invalid external clock selection. (Must be 0 or 1.)
E.39
Invalid record time option. ( Must be 0, 1 or 2, and the number of
samples cannot be L1.)
E.40
Insufficient coefficients entered for specified equation.
E.42
Invalid equation number. (Must be an integer from 0–4.)
E.43
Invalid equation type selected. (Must be an integer from 0–12.)
E.44
Equation order is out-of-range for model (see page 48).
E.49
Invalid units display option. (Must be an integer from 0–3.)
E.52
Invalid or out-of-range Channel Select value. (Must be 0, 1, 2, 3, 11, 21,
or L1. If L1, Record Time must be selected in
CMD3
.)
E.53
Invalid or out-of-range Data Select value. (Must be an integer from 0–5.
If 1, 2, 4, or 5, Post-processing = 1 or 2 in Cmd 1 must also be selected.)
E.54
Invalid or out-of-range Data Begin value. (Must be an integer 1 to
requested number of samples.)
E.55
Invalid or out-of-range Data End value. (Must be an integer
0 to requested number of samples, and ‚ Data Begin value unless
Data End = 0.)
E.62
Invalid Set/Reset parameter. (Must be 0 or 1.)
E.63
Invalid Multimeter mode operation. (Must be an integer from 1–8.)
POS
Power-on Short. The CBL detected a short on one or more of the +5
Volt DC supply pins, or a total current drain greater than 120 mA.
