82 CBLé System Guidebook
CMD5—Data Range Setup
CMD5 Syntax and Parameters
{5,channel,data_select,data_begin,data_end}
Channel Select Data Select Data Begin Data End
0 = lowest active channel
1
–
3, 11, 21
L1 = record time
0 = raw collected data
(filtered)
1 = d/dt (filtered)
2 = d
2
/dt
2
(filtered)
3 = raw collected data
(unfiltered)
4 = d/dt (unfiltered)
5 = d
2
/dt
2
(unfiltered)
1–512
0
–
512
(0 = get last
sample)
Notes: Data Select = 0, 1, 2; filtered if Filter = 1–6 in
CMD3
.
Data Select = 3, 4, 5; ignore filter setting in
CMD3
.
Data End must be greater than or equal to Data Begin (unless Data End = 0),
and both must be less than or equal to the number of samples sent to the CBL
in the last
CMD3
.
CMD6—Multimeter Mode Setup
CMD6 Syntax and Parameters
{6,set_reset,operation}
Set/Reset Operation
1
=
Set to multimeter mode
0 = Restore to communications
mode
1
=
AutoIDENT
or
voltage
(0
–
5 volts)
2= Voltage (±10V)
3= Current (±10A)
4= Resistance (1K
–
100K
Ω
)
5= Period (0.000004 sec to
50 sec)
6= Frequency (0.02 to250KHz)
7= Meters
8= Feet
Note: Operations Meters and Feet apply only to
CH11
(SONIC).
CMD7—Request Status
(Refer to page 53.)
