Hardware Setup for USB Dongle
www.ti.com
NOTE: The red stripe (pin 1) should be on the same side as the blue and 3 keys. When connected
properly, the debugger LED shows green after pressing the CC debugger reset button.
Power Savings Tip: Leaving the remote in debug mode causes extra power drain on the battery.
To exit debug mode, do the following:
1. Remove the debugger cable.
2. Power cycle the remote.
6.2 Hardware Setup for USB Dongle
The setup process for flashing the USB dongle is similar to the process of flashing the remote.
1. Connect the CC debugger to the USB dongle as shown in Figure 6-2.
