Texas Instruments CC2541 - Data Flow; HID Report Overview

www.ti.com HID over GATT
7.1.3 Data Flow
Figure 7-1 shows how HID reports are sent to a central device.
Figure 7-1. Data Flow
7.1.4 HID Report Overview
Table 7-3 shows the HID reports supported in the advanced remote control.
Table 7-3. HID Reports
Type Bytes Data Function Ref.
Mouse 4 Buttons, X, Y, wheel hidMouseSendReport
Consumer Control 2 Bitmap command hidCCSendReport
Keyboard 8 Modifier, reserved, key code 1.6 hidKeyboardSendReport
27
