Preface
SLAU138F – June 2004 – Revised March 2007
Read This First
About This Manual
This manual documents the Texas Instruments MSP-FET430 Flash Emulation Tool (FET). The FET is the
development tool for the MSP430 ultralow-power microcontroller. Both available interfaces, the parallel
port interface and the USB interface, are described here.
How to Use This Manual
Read and follow the instructions in Chapter 1 , Get Started Now!. This chapter lists the expected contents
of the FET, provides instructions on installing the hardware and software, and shows how to run the
demonstration programs. After you see how quick and easy it is to use the FET, TI recommends that you
read all of this manual.
This manual describes the setup and operation of the FET, but it does not fully describe the MSP430 or
the development software systems. For details of these items, refer to the appropriate TI and IAR™
documents listed in Section 1.12 , Important MSP430 Documents on the CD-ROM and Web.
This manual applies to the following tools (and devices):
• MSP-FET430PIF (debug interface with parallel port connection, for all MSP430 flash-based devices)
• MSP-FET430UIF (debug interface with USB connection, for all MSP430 flash-based devices)
The following tools contain the parallel port debug interface (MSP-FET430PIF) and the respective target
socket module:
• MSP-FET430X110 (for the MSP430F11xIDW, MSP430F11x1AIDW, and MSP430F11x2IDW devices)
• MSP-FET430P120 (for the MSP430F12xIDW and MSP430F12x2IDW devices)
• MSP-FET430P140 (for the MSP430F13xIPM, MSP430F14xIPM, MSP430F15xIPM, MSP430F16xIPM,
and MSP430F161xIPM devices)
• MSP-FET430P410 (for the MSP430F41xIPM devices)
• MSP-FET430P430 (for the MSP430F43xIPN devices)
• MSP-FET430P440 (for the MSP430F43xIPZ and MSP430F44xIPZ devices)
The following tools contain the USB debug interface (MSP-FET430UIF) and the respective target-socket
module:
• MSP-FET430U14 (for MSP430 devices in 14-pin PW packages)
• MSP-FET430U28 (for MSP430 devices in 20- and 28-in DW packages)
• MSP-FET430U38 (for MSP430 devices in 38-pin DA packages)
• MSP-FET430U23x0 (for MSP430F2330/F2350/F2370 devices in 40-pin RHA packages only)
• MSP-FET430U48 (for MSP430 devices in 48-pin DL package)
• MSP-FET430U64 (for MSP430 devices in 64-pin PM package)
• MSP-FET430U80 (for MSP430 devices in 80-pin PN package)
• MSP-FET430U100 (for MSP430 devices in 100-pin PZ package)
These tools contains the most up-to-date materials available at the time of packaging. For the latest
materials (data sheets, user's guides, software, application information, etc.), visit the TI MSP430 web site
at www.ti.com/msp430 , or contact your local TI sales office.
