1.6 Software Installation
1.7 Hardware Installation, MSP-FET430X110
1.8 Hardware Installation, MSP-FET430PIF
Software Installation
• Four or eight headers
MSP-FET430U14: Four PCB 1 × 7-pin headers (two male and two female)
MSP-FET430U28: Four PCB 1 × 14-pin headers (two male and two female)
MSP-FET430U38: Four PCB 1 × 19-pin headers (two male and two female)
MSP-FET430U23x0: Eight PCB 1 × 10-pin headers (four male and four female)
MSP-FET430U48: Four PCB 2 × 24-pin headers (two male and two female)
MSP-FET430U64: Eight PCB 1x16-pin headers (four male and four female)
MSP-FET430U80: Eight PCB 1x20-pin headers (four male and four female)
MSP-FET430U100: Eight PCB 1x25-pin headers (four male and four female)
• One small box containing two or four MSP430 device samples
MSP-FET430U14: MSP430F2013IPW
MSP-FET430U28: MSP430F123IDW and/or MSP430F1232IDW
MSP-FET430U38: MSP430F2274IDA
MSP-FET430U23x0: MSP430F2370IRHA
MSP-FET430U48: MSP430F4270IDL
MSP-FET430U64: MSP430F417IPM and MSP430F169IPM
MSP-FET430U80: MSP430FG439IPN
MSP-FET430U100: MSP430F449IPZ and MSP430FG4619IPZ
Consult the device data sheets for device specifications. Device errata can be found in the respective
device product folder on the web provided as a PDF document. Depending on the device, errata may
also be found in the device bug database at www.ti.com/sc/cgi-bin/buglist.cgi .
Follow the instructions on the supplied READ ME FIRST document to install the IAR Embedded
Workbench™ KickStart. Read the file <Installation Root>\Embedded Workbench x.x\430\doc\readme.htm
from IAR for the latest information about the Workbench. The term KickStart refers to the function-limited
version of Embedded Workbench (including C-SPY™ debugger). KickStart is supplied on the CD-ROM
included with each FET, and the latest version is available from the MSP430 web site.
The documents mentioned in the previous paragraph (and this document) can be accessed using: Start →
Programs → IAR Systems → IAR Embedded Workbench KickStart for MSP430 V3.
KickStart is compatible with Windows® 98, Windows 2000, Windows ME, Windows NT 4.0, and Windows
XP. However, the USB FET interface works only with Windows 2000 and Windows XP.
1. Connect the 25-conductor cable originating from the FET to the parallel port of your PC. The driver for
accessing the PC parallel port is installed during IAR Embedded Workbench installation. Note that a
restart is required after the IAR Embedded Workbench installation for the driver to become active.
2. Ensure that the MSP430F1121AIDW is securely seated in the socket and that its pin 1 (indicated with
a circular indentation on the top surface) aligns with the "1" mark on the PCB.
3. Ensure that jumpers J1 (near the non-socketed IC on the FET) and J5 (near the LED) are in place.
Schematics of the FET and its parts are presented in Appendix B .
1. Use the 25-conductor cable to connect the FET interface module to the parallel port of your PC. The
necessary driver for accessing the PC parallel port will be installed automatically during IAR Embedded
Workbench installation. Note that a restart is required after the IAR Embedded Workbench installation
for the driver to become active.
2. Use the 14-conductor cable to connect the parallel port debug interface module to a target board, such
as an MSP-TS430xxx target socket module.
Get Started Now!12 SLAU138F – June 2004 – Revised March 2007
