Bill of Materials www.ti.com
Table 19. Bill of Materials (continued)
Item # Designator Quantit Value PartNumber Manufacturer Description PackageReference
y
32 R3, R5, R10, R11, 18 0 ERJ-1GE0R00C Panasonic RES, 0, 5%, 0.05 W, 0201 0201
R22, R30, R38, R39,
R40, R41, R46, R56,
R60, R62, R65, R66,
R69, R71
33 R4, R7, R8, R9 4 3.3k CRCW04023K30JNED Vishay-Dale RES, 3.3 k, 5%, 0.063 W, 0402 0402
34 R12, R13, R14, R15, 9 1.00k CRCW02011K00FKED Vishay-Dale RES, 1.00 k, 1%, 0.05 W, 0201 0201
R27, R42, R43, R44,
R45
35 R20, R75, R76, R79, 5 3.83k CRCW02013K83FKED Vishay-Dale RES, 3.83 k, 1%, 0.05 W, 0201 0201
R80
36 R21, R24, R25, R26, 10 100k CRCW0201100KFKED Vishay-Dale RES, 100 k, 1%, 0.05 W, 0201 0201
R29, R33, R49, R52,
R55, R70
37 R28 1 15.0k CRCW040215K0FKED Vishay-Dale RES, 15.0 k, 1%, 0.063 W, 0402 0402
38 R72, R73, R74, R86, 8 560 CRCW0402560RJNED Vishay-Dale RES, 560, 5%, 0.063 W, 0402 0402
R87, R89, R90, R96
39 R77, R78 2 9.09k CRCW02019K09FKED Vishay-Dale RES, 9.09 k, 1%, 0.05 W, 0201 0201
40 R82, R92, R102 3 100k CRCW0402100KFKED Vishay-Dale RES, 100 k, 1%, 0.063 W, 0402 0402
41 R84 1 32.4k CRCW040232K4FKED Vishay-Dale RES, 32.4 k, 1%, 0.063 W, 0402 0402
42 R85 1 2.74k CRCW04022K74FKED Vishay-Dale RES, 2.74 k, 1%, 0.063 W, 0402 0402
43 R88, R97, R109 3 47.5k CRCW040247K5FKED Vishay-Dale RES, 47.5 k, 1%, 0.063 W, 0402 0402
44 R94 1 19.1k CRCW040219K1FKED Vishay-Dale RES, 19.1 k, 1%, 0.063 W, 0402 0402
45 R95 1 8.45k CRCW04028K45FKED Vishay-Dale RES, 8.45 k, 1%, 0.063 W, 0402 0402
46 R104 1 7.15k CRCW04027K15FKED Vishay-Dale RES, 7.15 k, 1%, 0.063 W, 0402 0402
47 R108 1 9.53k CRCW04029K53FKED Vishay-Dale RES, 9.53 k, 1%, 0.063 W, 0402 0402
48 S1 1 TDA04H0SB1 C&K Components DIP Switch, SPST 4Pos, Slide, SMT 6.2x2.0x6.2mm
49 S3 1 B3U-1000P Omron Electronic Components SWITCH TACTILE SPST-NO 0.05A 12V 3x1.6x2.5mm
50 TP1, TP2, TP3, TP4, 5 5019 Keystone Test Point, Miniature, SMT Test Point, Miniature, SMT
TP5
51 U1 1 W25Q80DVSNIG Winbond 3V, 8Mbit, Serial Flash Memory with Dual and Qual SPI, SOIC-8 SOIC-8
52 U2 1 TPS65982ABZQZR Texas Instruments TPS65982 Preview Specification, ZQZ0096A ZQZ0096A
53 U3, U4 2 TPD4E05U06DQA Texas Instruments 1, 4, 6 CHANNEL PROTECTION SOLUTION FOR SUPER-SPEED (UP TO 6 GBPS) DQA0010A
INTERFACE, DQA0010A
54 U5, U6, U7 3 TPS54335DRCR Texas Instruments 4.5V to 28V Input, 3A Output, Synchronous SWIFT Step-Down DC-DC Converter, DRC0010J
DRC0010J
55 C27, C30, C38, C41, 0 120pF GRM1555C1H121JA01D MuRata CAP, CERM, 120 pF, 50 V, +/- 5%, C0G/NP0, 0402 0402
C49, C52
56 D1 0 40V B340A-13-F Diodes Inc. Diode, Schottky, 40 V, 3 A, SMA SMA
57 FID1, FID2, FID3, 0 N/A N/A Fiducial mark. There is nothing to buy or mount. Fiducial
FID4, FID5, FID6
58 H1, H2, H3, H4 0 NY PMS 440 0025 PH B&F Fastener Supply Machine Screw, Round, #4-40 x 1/4, Nylon, Philips panhead Screw
59 H5, H6, H7, H8 0 1902C Keystone Standoff, Hex, 0.5"L #4-40 Nylon Standoff
60 J5 0 PPPC031LFBN-RC Sullins Connector Solutions Receptacle, 100mil, 3x1, Gold, TH Receptacle, 3x1, 2.54mm, TH
61 J7 0 15-91-2040 Molex Header, 100mil, 2x2, Tin, SMT 2x2 100mil Tin Header
36
TPS65982 Evaluation Module SLVUAF8C–June 2015–Revised November 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
