7.10 USB-PD TX Driver Voltage Adjustment Parameter (continued)
Recommended operating conditions; T
A
= –10 to 85°C unless otherwise noted
(1)
PARAMETER TEST CONDITIONS MIN NOM MAX UNIT
VTXP10 TX transmit peak voltage 1.045 1.1 1.155 V
VTXP11 TX transmit peak voltage 1.021 1.075 1.128 V
VTXP12 TX transmit peak voltage 0.998 1.05 1.102 V
VTXP13 TX transmit peak voltage 0.974 1.025 1.076 V
VTXP14 TX transmit peak voltage 0.95 1 1.05 V
VTXP15 TX transmit peak voltage 0.903 0.95 0.997 V
(1) VTXP voltage settings are determined by application code and the setting used must meet the needs of the application and adhere to
the USB-PD Specifications.
7.11 Port Power Switch Characteristics
Recommended operating conditions; T
A
= –10 to 85°C unless otherwise noted
PARAMETER TEST CONDITIONS
(3)
MIN TYP MAX UNIT
RPPCC PP_CABLE to C_CCn power switch resistance 312 mΩ
RPP5V PP_5V0 to VBUS power switch resistance 50 60 mΩ
RPPHV PP_HV to VBUS power switch resistance 95 135 mΩ
IHVACT
Active quiescent current from PP_HV pin,
EN_HV = 1
1
mA
IHVSD
Shutdown quiescent current from PP_HV pin,
EN_HV = 0
100
μA
IHVEXTACT
Active quiescent current from SENSEP pin,
EN_HV = 1
Configured as source 1
mA
Active quiescent current from VBUS pin,
EN_HV = 1
Configured as sink 3.5
mA
IHVEXTSD
Shutdown quiescent current from SENSEP pin,
EN_HV = 0
40
μA
IPP5VACT Active quiescent current from PP_5V0 1 mA
IPP5VSD Shutdown quiescent current from PP_5V0 100 μA
ILIMHV
(5)
PP_HV current limit, setting 0 1.007 1.118 1.330 A
PP_HV current limit, setting 1 1.258 1.398 1.638 A
PP_HV current limit, setting 2 1.51 1.678 1.945 A
PP_HV current limit, setting 3 1.761 1.957 2.153 A
PP_HV current limit, setting 4 2.013 2.237 2.46 A
PP_HV current limit, setting 5 2.265 2.516 2.768 A
PP_HV current limit, setting 6 2.516 2.796 3.076 A
PP_HV current limit, setting 7 2.768 3.076 3.383 A
PP_HV current limit, setting 8 3.02 3.355 3.691 A
PP_HV current limit, setting 9 3.271 3.635 3.998 A
PP_HV current limit, setting 10 3.523 3.914 4.306 A
PP_HV current limit, setting 11 3.775 4.194 4.613 A
PP_HV current limit, setting 12 4.026 4.474 4.921 A
PP_HV current limit, setting 13 4.278 4.753 5.228 A
PP_HV current limit, setting 14 4.529 5.033 5.536 A
PP_HV current limit, setting 15 5.033 5.592 6.151 A
