Time (10 Ps/div)
Current (A)
Voltage (V)
0 -4
1 -2
2 0
3 2
4 4
5 6
6 8
7 10
D009
I CC2
C_CC2
PP_CABLE
Figure 9-31. PP_CABLE to C_CCn Current Limit with a Hard Short
Time (500 Ps/div)
Current (A)
Voltage (V)
-1 -1
0 0
1 1
2 2
3 3
4 4
5 5
6 6
D010
I CC2
C_CC2
PP_CABLE
Figure 9-32. PP_CABLE to C_CCn Current Limit with a Hard Short (Extended Time Base)
TPS65982
SLVSD02E – MARCH 2015 – REVISED AUGUST 2021
www.ti.com
52 Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
Product Folder Links: TPS65982
