Premier Elite Ricochet Kits Quick Guide
INS626 15
Expander Setup
Remote Reset
PSU Monitor
Line Fault +ve
Defer Auto Arming
to enter a value, to accept
Sounder Options
Press to edit, to select an option, to change the option, to accept
E = Entry Tones Enabled
A = Alarm Tones Enabled
F = Fault Tones Enabled
C = Chime Tones Enabled
S = Service Tones Enabled
System Outputs
Panel Outputs
Use - to select an output, to edit, - to enter an output group, - to enter output
type,
to accept
Digi Outputs
Com? Channels
RedCARE Pins
Keypad Outputs
Use - to select device, to select network, to select an output, to edit, - to enter
an output group,
to enter output type, to accept
Expander Outputs
Custom Outputs
Use
to select output, - to select a switch, to edit, - to enter an output group, -
to enter output type, to accept
X-10 Outputs
Use - to select an output, to edit, - to enter an output group, - to enter output
type,
to enter House/device Number, to accept
Key Output Group Outputs Types
Not Used:
Press
to accept
System:
Use - to enter an output type or use to search, to accept
00: Phone Line Fault 18: UDL Lockout 35: Custom 4 Stage A
01: Mains Power Off 19: UDL Call Active 36: Custom 4 Stage B
02: Aux Fuse Fault 20:
UDL Enabled 37: Custom 4 Stage AB
03: Auxiliary Tamper 21:
Confirmed Alarm 38: Com 1 Fault
04: Bell Tamper 22:
Custom 1 Stage A 39: Com 2 Fault
05: Panel Lid Tamper 23:
Custom 1 Stage B 40: Com 1 No Signal
06: Engineer Working 24:
Com 2 No Signal
07: Confirm Devices 25:
Custom 2 Stage A 42: Coms Fault
08: Service Required 26:
Custom 2 Stage B 43: Radio Jamming
09: Bell Fuse Blown 27:
Radio RX Tamper
10: Battery Fault 28:
Radio-Pad Failed 47: Detector Test
11: Battery Test On 30:
No Radio Signal 48: ATS Remote Test
12: Courtesy Light 31:
Radio-Pad Lost 49: Dual Path Fault
13: System Open 30:
No Radio Signal 50: CIE Fault
14: Fully Arm 31:
Radio-Pad Lost 51: PSU Fuse Blown
15: Digi Failed 32: Custom 3 Stage A 52: PSU Battery Flt
16: Digi Successful 33: Custom 3 Stage B 53: WD Test Active
17: Digi Active 34: Custom 3 Stage AB
Area: 12/24/48/88/168
Use - to enter an output type or use to search, - to select an area, ( = all areas,
= areas A – H and I –P),
to accept
640
Use - to enter an output type or use to search, to select an area, to accept type, -
to select an area group (1-4), use to select areas A – H and I –P), to accept.
00: Intruder Alarm 19: Exit Mode 38: Chime Mimic 57: Zones Locked Out
01: Guard 1 Alarm 20: Entry/Exit Mode 39: Chime Enabled 58: All Armed
02: Guard 2 Alarm 21: Armed 40: DK First Knock 59: Auto Arm Disable
03: Entry Alarm 22: Full Arm 41: BP First Knock 60: Armed / Alarm
04: Confirmed Alarm 23: Part Armed 42: On Test 61: Intruder Alarm
05: 24Hr Audible 24: Part Arming 43: Test Fail 62: Speaker Mimic
06: 24Hr Silent 25: Force Arm 44: Internal Alarm 63: Full Arm/Exit
07: 24Hr Gas 26: Force Arming 45: Auto Arming 64: Detector Fault
