15
parameters, press key once before the letter “L” is displayed on the right hand side
of current needle bar number. Press key to cancel low embroidering speed setting.
If all color change sequence of a certain set needle bar shall be replaced by another needle
bar for embroidering, press key, then click the needle bar for replacement, all identical
needle bars are selected, Replace needle bar values according to requirements. Press
key once to exit replacement operation.
After the setting is completed, press key to save current setting. Press
key to return to main interface.
4.3-6-3 Sequin Design – optional device
If the current color changing sequence is sequin embroidery, press key to make
a free combination design of sequin (mechanical part is required). If the current color
changing is not sequin embroidery, press the key and it cannot enter into the operation.
After entering into setting interface, displays the max sequin number of
the current color change. Select the application method: A/B/AB according to requirements of
the design. Selected background has color change options. Input current output number in the
input box after the option. It can use a max of 9 different combinations.
When the combined sequin number is not set completely, the remaining boxes will be
output with automatic cycling according to current setting sequences.
The size of A/B sequin is determined by embroidery parameters.
Max sequin diameter of machine cannot be larger than the sequin size of embroidery design.
4.3-7 Change Color Sequence Mode
In the operation status interface, press key to change the color sequence mode.
Change one mode to another by pressing the key once (cycle changing) and the key display is
changed along with it. This means automatic changing color and automatic start mode,
automatic color changing and manual start mode, manual color changing and
manual starting mode.
