1.3 Working Environment
Good ventilation, healthy environment, less dust;
Working space temperature: 5-40 °C; 41-104 °F
Working Space Relative Humidity: 30% - 90% non-condensing.
1.4 System Power Supply and Grounding
The electric control system can use the following power:
Single phase AC100-220V/50-60HZ
Depending on the machines configurations, power consumption is between 0.1-0.4KW.
To prevent electrical equipment from causing electric shock or fire accidents due to
electric leakage, over-current or insulation and other causes, please ground the electrical
control system.
Grounding resistance shall be less than 100 ohm, wire length shall be within 20 m and wire
cross-section shall be greater than 1.0 mm
2
.
1.5 Operation Panel and Key Function
1.5-1 Key Function Introduction
Manual trimming key: You can do manual trimming in operation status and
preparation status.
Main shaft origin key: Press the key and main shaft returns to 100 degree.
1.5-2 Icons Description of Touch Keys
Frame speed key: Used to select hoop movement speed, from fast to slow.
Directional keys: Move hoops in operation status and preparation
status.
Main axis speed key: - key for deceleration, and + key for acceleration.
