Thecus N2200 User Manual

Chapter 2: Hardware Installation
Overview
Your N2200 is designed for easy installation. To help you get started, the following
chapter will help you quickly get your N2200 up and running. Please read it carefully
to prevent damaging your unit during installation.
Before You Begin
Before you begin, be sure to take the following precautions:
1. Read and understand the Safety Warnings outlined in the beginning of the
manual.
2. If possible, wear an anti-static wrist strap during installation to prevent static
discharge from damaging the sensitive electronic components on the N2200.
3. Be careful not to use magnetized screwdrivers around the N2200’s electronic
components.
Hard Disk Installation
The N2200 supports both 2.5” and 3.5” Serial ATA (SATA) hard disks. To install a
hard disk into the N2200, follow the steps below:
1. Open front cover of the N2200.
2. For 3.5” HDDs
a. Remove an HDD tray and install a 3.5” SATA hard disk onto it.
b. Slide the HDD tray back into the N2200 until it snaps into place.
3. For 2.5” HDDs
a. Remove an HDD tray and install a 2.5” SATA hard disk onto it.
b. Slide the HDD tray back into the N2200 until it snaps into place.
13

Thecus N2200 Specifications

General

RAID levels	0, 1, JBOD
Storage drive size	2.5/3.5 \
Storage drive capacity	2000 GB
Storage drive interface	Serial ATA, Serial ATA II
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	4 TB
Number of storage drives installed	2
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9/X
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Processor model	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Type	NAS
Device class	Home & Home Office
