Thecus N2200 User Manual

Edit RAID
On the RAID Information screen, press the Edit button to go to the RAID
Information screen.
Using Edit RAID, you can select RAID ID and the Spare Disk. .
Remove RAID
Click to remove the RAID volume. All user data has been created in selected RAID
volume will be removed.
To remove a RAID volume, follow the steps below:
1. On the RAID List screen, select the RAID volume by clicking on its radio
button, and click RAID Information to open the RAID Configuration
screen.
2. On the RAID Configuration screen, click Remove RAID.
3. The confirmation screen appear, you will have to input “Yes” with exactly
wording case to complete “Remove RAID” operation
Remove RAID destroys a
unrecoverable.
ll data in the current RAID volume. The data is
WARNING
Share Folder
From the Storage menu, choose Share Folder, and the Folder screen appears.
This screen allows you to create and configure folders on the N2200 volume.
46

Thecus N2200 Specifications

General

RAID levels	0, 1, JBOD
Storage drive size	2.5/3.5 \
Storage drive capacity	2000 GB
Storage drive interface	Serial ATA, Serial ATA II
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	4 TB
Number of storage drives installed	2
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9/X
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Processor model	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Type	NAS
Device class	Home & Home Office
