Thecus N2810 Series User Manual

53
Quality of Service Configuration
Enable the Rule
Checked the box to enable defined rule.
Network Interface
Select network interface from drop down list.
Service List
Select desired service to have QoS served
User Defined
Other than pre-defined service list, user defined service is
allowed.
Service Name
Input user defined service name
Protocol and Ports
Input user defined protocol from drop down list and associated
ports will be used
Protocol
List associated protocol of selected service.
Ports
List associated port number of selected service.
Guaranteed (KB/s)
Input MUST of throughput for associated service.
Maximum (KB/s)
Input maximum of throughput for associated service
To modify, delete or change priority of created QoS service, select desired service
from service list then click required activities. Carry on for necessary modification
to modify by click “Edit” or click on “Move Up” or “Move Down” to change priority.
The Delete the rule button can be found on left hand bottom corner after go into
“Edit” screen.
DDNS
DDNS Support:
To set up a server on the Internet and enable the users to connect to it easily, a
fixed and easy-to remember host name is often required. However, if the ISP
provides only dynamic IP address, the IP address of the server will change from
time to time and is difficult to recall. You can enable the DDNS service to solve
the problem.
After enabling the DDNS service of the NAS, whenever the NAS restarts or the IP
address is changed, the NAS will notify the DDNS provider immediately to record
the new IP address. When the user tries to connect to the NAS by the host name,
the DDNS will transfer the recorded IP address to the user.
The NAS supports the DDNS providers:
DyDNS.org(Dynamic DNS),DyDNS.org(Custom DNS),DyDNS.org(Static DNS),
www.zoneedit.com,www.no-ip.com.
A description for each item as following:
