Thecus N4200 User Manual

1
17
Setting up an Nsync Target on an Thecus IP storage Nsync Device
On the Nsync target server, the administrator of that server has to set up a user
account with a folder named “nsync” and grant write access.
1. On the Nsync server, add a user for Nsync source (ex. nsyncsource1). For
instructions on how to add a user on the Thecus IP storage, see Chapter 4:
User and Groups Authentication> Local User Configuration > Add
Users.
2. On the Nsync server, grant that user (ex. nsyncsource1) write access to the
nsync folder. For instructions on how to set up a folder’s ACL, see
Chapter 4: Storage management> Shore Folder> Folder Access
Control List (ACL).
3. Once this is done, the target server will start accepting Nsync tasks from
server using that ID and password.
Setting Up an Nsync Target on another Device other than Thecus IP
storage
If you selected “Legacy FTP Server” when setting up your Nsync task, the Thecus IP
storage will use the FTP protocol to back up the share folder. On the external storage
device, make sure there is a folder named “nsync”, and the Auth ID has writable
permission in that folder.
Designating Thecus IP storage as an Nsync Target
The Thecus IP storage can act as an Nsync server, enabling another Nsync-equipped
Thecus NAS at a remote location backup their files to this Thecus IP storage. From
the System Network menu, choose the Nsync Target item, and the Nsync
Target Server screen appears.
Nsync Target Server Setting
Item Description
Nsync Target Server Enable or Disable Nsync Target support.
Dual DOM (except N0503/N4200Eco/N7700/N8800)
The unique Dual DOM feature can now perform “Auto Repair”. The Thecus NAS will
backup up to five versions of the system configuration either by the default timing of
1:00am every day automatically or as scheduled by the user.
This unique “Auto Repair” will be triggered if the primary DOM has a booting issue.
In this instance, the 2
nd
DOM will take over the boot function. Then, the system will
automatically load the most recent system configuration backup image to repair the
primary DOM.
NOTE
To enable Nsync task to go thru firewall, you have to open port TCP/1194 on
your firewall in both directions.

Thecus N4200 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive capacity	- GB
Supported file systems	Ext3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	-
Number of storage drives supported	4
Internal memory	1 GB
Internal memory type	DDR2
Bus type	DMI
Stepping	B0
Tjunction	100 °C
Processor code	SLBLA
Processor cache	1 MB
Processor cores	2
Processor model	D510
System bus rate	- GT/s
Processor family	Intel Atom®
Processor socket	BGA 559
Processor codename	Pineview
Processing Die size	87 mm²
Processor frequency	1.66 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	22 x 22 mm
Conflict-Free processor	No
Processor operating modes	64-bit
Thermal Design Power (TDP)	13 W
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Memory bandwidth supported by processor (max)	6.4 GB/s
Maximum internal memory supported by processor	4 GB
Link/Act LED	Yes
Expansion slots	PCI-e x1
Processor ARK ID	43098
Networking features	Gigabit Ethernet
Compatible operating systems	- Windows 2000/7/XP/2003/Vista; - UNIX/Linux; - Mac OS 9 / X
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP, Appletalk, SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Security algorithms	256-bit AES
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display type	OLED
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Number of Processing Die Transistors	176 M
Memory channels supported by processor	Single
