Thecus N4200 User Manual

138
Chapter 6: Tips and Tricks
USB and eSATA Storage Expansion
The Thecus IP storage supports external USB hard disks through its USB ports. Once
a USB hard disk has successfully mounted, the entire volume will be linked
automatically to the default USB HDD folder. The Thecus IP storage supports USB
external storage devices. All file names on the USB disk volume are case sensitive.
The Thecus IP storage also supports eSATA hard disks with its eSATA port.
Before attaching an eSATA or USB disk drive to Thecus IP storage, you have to
partition and format it on a desktop computer or a notebook first. The attached
device will be located at \\192.168.1.100\usbhdd\sd(x)1 where 192.168.1.100
means the IP address of Thecus IP storage and sd(x)1 stands for the first partition
on the eSATA or USB disk drive.
Adding a Spare Disk
With a RAID 1, RAID 5, RAID 6, or RAID 10 volume, you can add a spare disk after
the initial RAID is setup. To add a spare disk, follow the steps below:
1. On the RAID Configuration Screen, tick the checkbox of the hard disk you
wish to designate as a spare disk.
2. Click Add Spare. The disk will be configured as a spare disk. The system
automatically rebuilds the spare disk when one of the disks in the RAID set
fails.
Remote Administration
You can set up your Thecus IP storage for remote administration. With remote
administration, you can access your Thecus IP storage over the Internet, even if
your Thecus IP storage is behind a router. This is especially useful if you are
traveling and suddenly need a file from your Thecus IP storage.
Setting up remote administration is a three-part process, and will require the
following equipment:
 Thecus IP storage device
 Cable / DSL Router with Dynamic DNS support
 Home PC
 Internet Connection
NOTE
Router setup will differ slightly depending on router used. For this example,
we will use the Asus WL500g because it has support for Dynamic DNS.
Contact your router hardware vendor for setup help.

Thecus N4200 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive capacity	- GB
Supported file systems	Ext3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	-
Number of storage drives supported	4
Internal memory	1 GB
Internal memory type	DDR2
Bus type	DMI
Stepping	B0
Tjunction	100 °C
Processor code	SLBLA
Processor cache	1 MB
Processor cores	2
Processor model	D510
System bus rate	- GT/s
Processor family	Intel Atom®
Processor socket	BGA 559
Processor codename	Pineview
Processing Die size	87 mm²
Processor frequency	1.66 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	22 x 22 mm
Conflict-Free processor	No
Processor operating modes	64-bit
Thermal Design Power (TDP)	13 W
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Memory bandwidth supported by processor (max)	6.4 GB/s
Maximum internal memory supported by processor	4 GB
Link/Act LED	Yes
Expansion slots	PCI-e x1
Processor ARK ID	43098
Networking features	Gigabit Ethernet
Compatible operating systems	- Windows 2000/7/XP/2003/Vista; - UNIX/Linux; - Mac OS 9 / X
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP, Appletalk, SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Security algorithms	256-bit AES
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display type	OLED
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Number of Processing Die Transistors	176 M
Memory channels supported by processor	Single
