Thecus N4200 User Manual

121
Chapter 5: Using Thecus IP Storage
Overview
Once the Thecus IP storage is setup and operating, users on the network may
manage all varieties of digital music, photos, or files by simply using their web
browsers. To manage your personal files or access public files on the Thecus IP
storage, just enter its IP address into your browser (default IP address is
http://192.168.1.100), and you will be taken to the Thecus IP storage Login
page.
Login Page
To login to the system, enter your user name and password, and select Web Disk or
Photo server then click Login to log into the system. You will be taken to the
selected interface.
Using WebDisk
The Thecus IP storage provides a WebDisk function that allows you to access the
system over the Internet from any browser.
1. In the Login page, type in the User ID and password that were previously set
for you in the Accounts menu. See
Chapter 4:User and Group Authentication > Local User Configuration.
2. The WebDisk page appears showing folders made currently available to you
via the Access Control List (ACL).
3. Click on a folder name to enter the folder.
4. The folder’s page appears displaying files and folders. Click on a file to
download the file.
NOTE
Before proceeding, make sure that WebDisk Support or Secure WebDisk Support is
enabled in the Service Support screen in the system’s Network menu. See Service
Support in Chapter 4: System Network >HTTP/Web Disk.

Thecus N4200 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive capacity	- GB
Supported file systems	Ext3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	-
Number of storage drives supported	4
Internal memory	1 GB
Internal memory type	DDR2
Bus type	DMI
Stepping	B0
Tjunction	100 °C
Processor code	SLBLA
Processor cache	1 MB
Processor cores	2
Processor model	D510
System bus rate	- GT/s
Processor family	Intel Atom®
Processor socket	BGA 559
Processor codename	Pineview
Processing Die size	87 mm²
Processor frequency	1.66 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	22 x 22 mm
Conflict-Free processor	No
Processor operating modes	64-bit
Thermal Design Power (TDP)	13 W
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Memory bandwidth supported by processor (max)	6.4 GB/s
Maximum internal memory supported by processor	4 GB
Link/Act LED	Yes
Expansion slots	PCI-e x1
Processor ARK ID	43098
Networking features	Gigabit Ethernet
Compatible operating systems	- Windows 2000/7/XP/2003/Vista; - UNIX/Linux; - Mac OS 9 / X
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP, Appletalk, SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Security algorithms	256-bit AES
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display type	OLED
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Number of Processing Die Transistors	176 M
Memory channels supported by processor	Single
