Thecus N4200 User Manual

55
LAN2 Configuration
Item Description
MAC Address Displays the MAC address of the LAN2 interface.
Jumbo Frame Support
Enable or disable Jumbo Frame Support on the LAN2 interface.
IP Specifies the IP address of the LAN2 interface.
Netmask Specifies the Network Mask of the LAN2 interface.
Gateway When Thecus NAS as a DHCP server from LAN2, it can have
another route to balance traffic bandwidth for its DHCP
clients
Link Detected Specifies the LAN2 port link status
Lick Speed Specifies the LAN2 port link speed
DHCP Server Configuration
A DHCP server can be configured to assign IP addresses to devices connected to the
LAN2 port. To configure these ports, choose LAN2 from the System Network
menu.
DHCP Configuration
Item Description
DHCP Server Enable or disable the DHCP server to automatically assign IP
address to PCs connected to the LAN2 interface.
Start IP Specifies the starting IP address of the DHCP range.
End IP Specifies the ending IP address of the DHCP range.
DNS Server Displayed the DNS server IP address.
Samba / CIFS
There are 5 options is currently allow Admin to Enable/Disable to operate Thecus IP
storage associated with Samba / CIFS protocol. With the option changed, it will need
to reboot system to activate.
NOTE
Before enabling Jumbo Frame Support, please make sure your network equipment
supports Jumbo Frame. If your equipment is incompatible, you might not be able to
connect to your Thecus IP storage.
NOTE
The IP Segment of WAN/LAN1 and LAN2 should not overlap.
WARNING
The IP address of the LAN2 interface should not be in the range of the
Start IP address and End IP address.
NOTE
If the IP sharing mode setting is set to “Enable” under WAN/LAN21 port, then this 2
nd
gateway cannot be configured.

Thecus N4200 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive capacity	- GB
Supported file systems	Ext3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	-
Number of storage drives supported	4
Internal memory	1 GB
Internal memory type	DDR2
Bus type	DMI
Stepping	B0
Tjunction	100 °C
Processor code	SLBLA
Processor cache	1 MB
Processor cores	2
Processor model	D510
System bus rate	- GT/s
Processor family	Intel Atom®
Processor socket	BGA 559
Processor codename	Pineview
Processing Die size	87 mm²
Processor frequency	1.66 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	22 x 22 mm
Conflict-Free processor	No
Processor operating modes	64-bit
Thermal Design Power (TDP)	13 W
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Memory bandwidth supported by processor (max)	6.4 GB/s
Maximum internal memory supported by processor	4 GB
Link/Act LED	Yes
Expansion slots	PCI-e x1
Processor ARK ID	43098
Networking features	Gigabit Ethernet
Compatible operating systems	- Windows 2000/7/XP/2003/Vista; - UNIX/Linux; - Mac OS 9 / X
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP, Appletalk, SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Security algorithms	256-bit AES
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display type	OLED
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Number of Processing Die Transistors	176 M
Memory channels supported by processor	Single
