Hard Disk Trays
Each of the N7700SAS’s hard disk trays has
a lock, a latch, and two LED indicators:
3 4 5
1
2
Hard Disk Trays
Item Description
1.HDD Power LED Solid blue: hard disk is powered on
2.HDD
Access/Error LED
Blinking green: system is accessing data on the hard disk
3.Lock Use the lock to physically secure the hard disk to the unit
4.Latch Use to open and remove or close and secure the tray
5.Handle Pull out HDD tray
Rear Panel
The N7700SAS rear panel features ports and connectors.
