RAID

X X [ONLINE]

[RAID 6] HDDx4 to [RAID 6] HDDx5

[RAID 6] HDDx4 to [RAID 6] HDDx6

[RAID 6] HDDx4 to [RAID 6] HDDx7

[RAID 6] HDDx5 to [RAID 6] HDDx6

[RAID 6] HDDx5 to [RAID 6] HDDx7

[RAID 6] HDDx6 to [RAID 6] HDDx7

Space Allocation

You may specify the space allocated for iSCSI volumes. The iSCSI volume can be

created up to 5 volumes per RAID volume.

To do this, under the Storage menu, click RAID and the RAID List window

appears. Select the RAID volume you wish to reallocate by clicking on its radio

button, and click Space Allocation. The RAID Information and Volume

Allocation List windows will appear.

The Volume Allocation List displays the space allocated for iSCSI volumes on the

current RAID volume. The N7700SAS supports up to five iSCSI volumes.

Volume Allocation List

Item Description

Modify Click this to modify the allocated space.

Delete Click this to delete the allocated space.

iSCSI Target Click to allocate space to iSCSI volume.

Type Type of volume. Can be either USB or iSCSI.

Name Name assigned to the volume.

Capacity Capacity of the allocated space.

Thecus N7700SAS User Manual
