Chapter 4: System
Overview
The N7700SAS provides an easily accessible Web Administration Interface. With
it, you can configure and monitor the N7700SAS anywhere on the network.
Web Administration Interface
Make sure your network is connected to the Internet. To access the N7700SAS Web
Administration Interface:
1. Type the N7700SAS’s IP address into your browser. (Default IP address is
http://192.168.1.100)
NOTE
Your computer’s network IP address must be on the same subnet as the
N7700SAS. If the N7700SAS has default IP address of 192.168.1.100, your
managing PC IP address must be 192.168.1.x, where x is a number between 1
and 254, but not 100.
2. Login to the system using the administrator user name and password. The
factory defaults are:
User Name: admin
Password: admin
※ If you changed your password in the setup wizard, use the new password.
Once you are logged in as an administrator, you will see the Web Administration
Interface. From here, you can configure and monitor virtually every aspect of the
N7700SAS from anywhere on the network.
Menu Bar
The Menu Bar is where you will find all of the information screens and system
settings of the N7700SAS. The various settings are placed in the following groups on
the menu bar:
23
