DRAG-GUN PLUS 35C
Inroduction 1-2 Manual 0-4750
2.04 Torch Specifications
Art # A-04653
10.5 in (266.7 mm)
3 in
(76.2 mm)
Torch Configuration
Torch Head at 70° to
Torch Handle
Torch Leads Len
g
th 20 feet / 6.1
m
Ambient
Temperature
104° F
40° C
Duty Cycle
100% @ 40 Amps
@ 200 scfh
Maximum Current
40 Amps, DC,
Straight Polarity
Voltage (V
p
ea
k
) 500V
Arc Striking Voltage 12kV
Type of Cooling
Ambient air and gas
stream through torch
Parts-in-Place:
Built-in Switch
in Torch Head
Gas Requirement:
Single Gas,
Compressed Air Only
Input
Gas Pressure
65 psi (4.5 bar)
(.45MPa)-
125 psi (8.6 bar)
(.86MPa)
Minimum Gas Flow
200 SCFH (142 lpm)
Direct Contact Hazard
For operation with
exposed tip the
recommended standoff
height is
1/8 - 3/8" (3-9 mm).
Plasma Power Supply
used with:
Drag-Gun Plus
PCH-42 Torch Ratin
g
s
2.05 System Contents
Descri
p
tion ITEMS Q't
y
Power Source Model Drag-Gun Plus 1
Torch Set
PCH-42, with 20'
(6.1 m) leads
1
Accessories &
Consumables
Work Cable
Manual
Torch Electrodes
Torch Tips
1
1
2
3
Input Power
Cable U.S. /
CAN.
3 Meter NEMA 10 AWG /
4.8 mm
2
with 6 - 50 P
molded plug
1
Input Power
Cable Outside
of U.S. / CAN.
3 Meter 3x2.5 sq mm
rubber wire
1
2.06 Transporting Methods
Lift unit with handle on top of case. Use handcart or similar
device of adequate capacity for transporting.
WARNING
ELECTRIC SHOCK can kill. DO NOT TOUCH live
electrical parts. Disconnect input power from sup-
ply before moving the power source.
