DRAG-GUN PLUS 35C
Manual 0-4750 3-1 Installation
SECTION 3:
INSTALLATION
3.01 Site Selection
• Place in a clean and dry area.
• Provide adequate ventilation and fresh air supply.
• Ideal ambient temperature should not exceed 40°C /
104°F. Temperatures exceeding that may diminish cut-
ting capacity or quality.
• The cutting machine must be placed on an even, firm
surface so that it stands firmly.
WARNING
This equipment must be electrically connected by
a qualified electrician.
3.02 Electrical Input Connections
• Input voltage is 230V ± 10%, 50/60 Hz single phase.
CAUTION
Check your power source for correct voltage be-
fore plugging in or connecting the unit. The pri-
mary power source, fuse, and any extension
cords used must conform to local electrical code
and the recommended circuit protection and wir-
ing requirements as specified in Section 2.
3.03 Torch
• Make sure that the torch cable and torch switch termi-
nals are connected to front panel.
• Make sure the Work Cable is connected properly to front
panel.
• Before activating, turn torch away from yourself and
others.
DANGER
Do not cut in humid or wet surroundings.
• Before you maintain or replace torch parts, wait for the
post flow air cycle to stop, then turn the machine off.
• Always use original manufacturers parts. The use of
aftermarket parts could result in lower parts life and in
unsatisfactory cutting results. Any warranty claims
would be waived.
• Recycle worn parts according to local requirements.
NOTE
Repairs must be done by skilled and qualified
personnel only.
