CUTMASTER A80
PARTS LIST 6-4 Manual 0-4985
6.06 Torch Replacement Parts SL100SV Torch (with Solenoid on Mounting
Tube)
Item No. Qty Description Catalog No.
1 1 Torch Head Assembly without leads (includes items 2, 3, and 14) 9-8220
2 1 Large O - Ring 8-3487
3 1 Small O - Ring 8-3486
4 1 PIP Switch Kit 9-7036
5 1 PIP Plunger and Return Spring Kit 9-7045
6 Automated Leads Assemblies with ATC connectors
1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-3058
1 35 - foot / 10.6 m Leads Assembly with ATC connector 4-3059
1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-3060
7 1 Rack 9-9448
8 1 Mounting Tube 9-9445
9 1 End Cap Assembly 9-7044
10 2 Body, Mounting, Pinch Block 9-4513
11 1 Pin, Mounting, Pinch Block 9-4521
12 1 Torch Holder Sleeve 7-2896
13 1 Pinion Assembly (does not include positioning tube) 7-2827
14 1 Torch Holder Sleeve 7-2896
15 1 Pinion Gear-Short 8-6074
16 1 Handwheel (Torch Holder) 9-4514
17 1 Low Prole Torch Holder (1 3/8 Dia) w/o Hardware 9-4515
18 1 Calibrated Torch Holder Bushing 9-4366
19 1 5/32 Dia x 5/8 Lg Slotted Spring Pin See Note 1
20 1 3/8-24 x 3/8 Soc Hd Set Screw, Cup Point See Note 1
21 2 1/4-20 x 5/8 Hex Socket Head Screw See Note 1
22 1 #10-24 x 3/8 Hex Socket Set Screw, Cup Point See Note 1
23 1 Solenoid Assembly 9-9447
24 1 Solenoid Cover 9-9446
NOTE 1
Purchase these parts locally.
