CUTMASTER A80
Manual 0-4985 2-3 INTRODUCTION
2.05 Input Wiring Specifications
CutMaster A80 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I
1
eff Fuse(amps)
FlexibleCord
(Min. AWG)
FlexibleCord
(Min. mm
2
)
1 Phase
208 60 20.6 99 76 100 4 Type W 25 Type W
230 60 21.9 95 74 100 4 Type W 25 Type W
460 60 27.6 60 46 60 6 15
3 Phase
208 60 17.7 49 38 60 6 15
230 60 17.9 45 36 60 6 15
380 50 18.4 28 22 32 10 6
400 50 18.7 27 22 32 10 6
460 60 23.1 29 22 30 10 6
600 60 22.8 22 17 25 12 4
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
The suggested sizes are based on exible power cable with power plug installations. For hard-wired installations
refer to local or national codes.
I
1
max is taken at TDC rated minimum duty cycle.
I
1
e is taken at TDC 100% rated duty cycle.
