CUTMASTER A40
Manual 0-4978 2-3 INTRODUCTION
2.05 Input Wiring Specifications
CutMaster A40 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I1eff Fuse(amps)
FlexibleCord
(Min.AWG)
1 Phase
208 60 10.4 47 30 50 10
230 60 10.8 45 29 50 10
460 60 15.2 31 20 35 12
3 Phase
208 60 5.4 26 17 30 12
230 50/60 5.8 24 16 30 12
380 50/60 6.1 16 11 20 14
400 50/60 6.4 16 11 20 14
460 60 7.4 16 10 20 12
600 60 7.8 13 11 15 12
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired instal-
lations refer to local or national codes.
An energy limiting fuse UL Class RK-1 (examples: BUSS LPS/LPN-RK or Gould-Shawmut AZK-A6K) should
be used to minimize damage to Plasma Cutting, Welding or power distribution equipment.
NEVER use replaceable element fuses like UL Class H, or “one-time” fuses like UL Class K5.
