CUTMASTER A40
Manual 0-4978 6-1 PARTS LIST
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as fol-
lows:
Section "6.03 Power Supply Replacement"
Section "6.04 Replacement Power Supply Parts"
Section "6.05 Options and Accessories"
Section "6.06 Torch Replacement Parts SL100SV Torch (with Solenoid on Mounting Tube)"
Section "6.07 Torch Consumable Parts (SL100 SV) Automation"
Section "6.08 Torch Consumable Parts Manual (SL60)Torch"
Section "6.09 Replacement Parts for Hand Torch"
NOTE
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper
authorization will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in
the parts list for each type item. Also include the model and serial number of the power supply. Ad-
dress all inquiries to your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power
cable, gas pressure regulator / lter, and operating manual.
Qty Description Catalog #
1 CutMaster
A60 Power Supply
208/230 - 460VAC, Single or 3 Phase, 60Hz,
with input power cable and plug 3-5134-1
460VAC, Single or 3 Phase, 60Hz, with input power cable 3-5134-2
400/415VAC Non CE, Three - Phase, 50 Hz, with input power cable 3-5134-3
400/415VAC CE, Three - Phase, 50 Hz, with input power cable 3-5134-4
600VAC, Three - Phase, 60 Hz, with input power cable 3-5134-5
To Next Page
